Technical Characteristics:
Number of Contacts
24
Electrical Data Acc.to
DIN EN60664 EN61984
Rated Current
16A
Rated Voltage500VRated Impulse Voltage6KVPollution Degree3Flammability Acc.to (UL94)V0Insulation&nbsp;



Resistance≥1010ΩMaterialPolycarbonateLimiting Temperature-40℃~+125℃Mechanical Working Life≥500  Rated Voltage Acc.To UL/CSA600V
Contacts:
Material
Copper Alloy
Surface
Hard-silver,Hard Gold Plated
Contact Resistance
≤1mΩ
Crimp Teminal
- Wire Gauge
-AWG
-Stripping Length
0.14-4.0mm2
26-12
7.5mm
Screw Teminal
-Wire Gauge
-AWG
-Tightening Torque
-Stripping Length
0.14-2.5mm2
26-14
0.5Nm
7.0mm
Cage Clamp
-Wire Gauge
-AWG
-Stripping Length
0.14-2.5mm2
26-14
7.0-9.0mm
More details chec our <a href="//www.umerconnector.com" target="_self">WZUMER</a> website.

HE-024-M Han Heavy duty connector

24pins heavy duty connector with male and female inserts,hoods and housing,

WENZHOU YUMAO ELECTRICITY TECHNOLOGY CO.,LTD

Overview

Contact Details

Categories

Listings

Products

HE-024-M Han Heavy duty connector

$10-25
