Wuhan CenterRise M&C Engineering CO., Ltd.

LAG-S100 Ladle Slag Detection System (Eddy Current)
Overview
The continuous casting ladle slag detection device is used to detect the slag content of the ladle nozzle in the steelmaking continuous casting process, so as to improve the cleanliness of the tundish molten steel and obtain the best yield of the ladle molten steel. The device adopts the principle of electromagnetic induction detection.
The meaning of slag detection
To achieve high output: In order to ensure the cleanliness of molten steel in the ladle, if we detect slag by eyes, we often close the ladle prematurely, so that it will reduce the yield of molten steel. However, if we use slag detection system, we can detect slag accurately and timely, so that the amount of residual steel is controlled at 1%-2% to achieve high output.
Improve the cleanliness of molten steel: The steelmaking slag gets into the tundish is the main reason that affects the cleanliness of finished steel. The use of the slag detection system can reduce the amount of steelmaking slag carried into the tundish to a very small amount, and can also reduce the defects on the slab surface at least 80%.
Avoid blockage of the nozzle: The steelmaking slag gets into the tundish is also the main reason for the blockage of the nozzle due to secondary oxidation. After using the slag detection system, the blockage of the nozzle can be greatly reduced.

LAG-S100 Ladle Slag Detection System (Eddy Current)

continuous casting ladle slag detection device is used to detect the slag content of the ladle nozzle in the steelmaking continuous casting process

SPD-V020 Multifunctional Strand Condition Monitor
Overview
In the production process of the multifunctional strand condition monitor, in order to ensure the quality of the slab, it is necessary to strictly control the performance and various parameters of the CCM’s guide roll within a certain error range. Due to the continuous casting machine (CCM) is large and in a harsh production environment, it is difficult to measure the performance of the continuous casting machine manually, and many parameters are difficult to measure. Therefore, it is very important to have a set of equipment that can simulate drawing of steel billet to realize the measurement of CCM’s various parameters and performance. The multifunctional strand condition monitor uses various sensors to realize the measurement of CCM’s roll gap value, the arc value of continuous casting section, the rotation quality of the rolls, and the water spray pressure under the condition of simulating drawing of steel billet. Therefore, the CCM’s quality can be controlled in real time, and it is convenient for the maintenance personnel to analyze the CCM’s measurement results. The problem areas of the casting machine equipment can also be found. If these problems doesn’t be found in time, it will cause the bad quality of CCM’s products, the steel breakout in pouring process, surface and internal cracks and centerline segregation.

SPD-V020 Multifunctional Strand Condition Monitor

It can realize the measurement of CCM’s roll gap value, the arc value of continuous casting section, the rotation quality of the rolls etc

Overview
The continuous casting vibration type ladle slag detection device is used to detect the slag content of the ladle nozzle in the steelmaking continuous casting process, so as to improve the cleanliness of the tundish molten steel and obtain the best yield of the ladle molten steel. The device adopts the principle of vibration detection.It has a real field application value as a continuous casting ladle slag automatic detection system.
The meaning of the system
1. Reduce the amount of tundish slag
2. Improve the purity of molten steel
3. Improve the life of the tundish
4. Reduce sliding nozzle erosion
5. Reduce nozzle blockage
6. Increase the number of continuous pouring furnaces
7. Reduce the amount of residual steel in the ladle when high-quality steel is casting
8. Improve the yield of molten steel
9. Improve the quality of continuous casting billets
In order to improve the purity of the molten steel in the tundish, and improve the quality of the casting billet, especially to improve the quality of the billet in the transition section, and reduce the amount of residual steel in the high-quality ladle, and prolong the life of the tundish lining, and increase the number of continuous casting furnaces, it’s necessary to detect and control the slag in the later stage of continuous casting ladle casting.

LAG-S200 Ladle Slag Detection System (Vibration Type)

It is uesd to improve the cleanliness of the tundish molten steel and obtain the best yield of the ladle molten steel.

<h1>Handheld Thermocouple Calibrator</h1>
<h1>Model: LGK-JS02-064</h1>
Overview
LGK-JS02-064 handheld thermocouple calibrator is a product independently developed and designed by Wuhan CenterRise M&amp;C Engineering Co., Ltd. The calibrator can measure the temperature detected by two thermocouples.
We fully consider the customer's needs. In order to be used conveniently, our calibrator pursues accuracy, stability, durability and beauty in research and development and design. At the same time, it is also committed to the characteristics of small size, flexibility, simple operation, and long standby time.
Working principle
The LGK-JS02-064 handheld thermocouple calibrator reads the temperature data of the thermocouple sensor at a single point through a special chip, and then displays it on the screen through a nixie light.
<h2></h2>

The above picture shows the front view of the LGK-JS02-064 handheld thermocouple calibrator. As can be seen from the above figure, the instrument has one switch button, two operation buttons, one interface to be calibrated and LCD display.
Technical parameters
Test temperature range: 0-1000℃
Operating temperature: 0°C-50°C
Common working section 25°C-800°C
Power supply: 2 AA dry batteries

Handheld Thermocouple Calibrator

It reads the temperature data of thermocouple sensor at a single point through a special chip, and displays it on the screen through a nixie light.

Overview:
The BPS-K600 continuous casting mould breakout prediction system is developed by Wuhan CenterRise M&amp;C Measuring Co., Ltd. It adopts artificial neural network and combines with traditional artificial intelligence and information processing technology to overcome the defects of traditional logic-based prediction models. It has the functions of self-adaptation, self-organization and real-time learning.
The breakout prediction system has an optimized industrial network structure. According to the distribution and change rules of the temperature field of the mold, it can track and respond to the breakout process in real time. It can learn and judge by itself, and provide early warning information for on-site operations. It can effectively prevent the occurrence of breakout accidents, greatly reducing the cost and improving the safety factor of continuous casting.
The system is suitable for all kinds of continuous casting machines such as square billet, round billet, rectangular billet and slab.

The features of the system
<ol>
<li>1. Reasonable design of temperature measurement point and professional protection front-end acquisition system, and complete installation and calibration tool components.</li>
<li>2. The system has strong adaptability and can meet the transformation of various structural continuous casting machines.</li>
</ol>

BPS-K600 Mould Breakout Prediction System

According to the distribution and change rules of the temperature field of the mold, it can track and respond to mold breakout process in real time.
